Recycle Timer, Recycling Timer, Flasher.

A repeat cycle timing relay is an electrical device used to control the on/off operation of a load or circuit with repeated cycles. It provides a repeating or cyclical timing function, where the on-time and off-time durations can be independently set or adjusted.

Application of power to the input voltage terminals starts the “Off” delay cycle. At the end of the “Off” delay period, the load is energized and the “On” delay starts. At the end of the “On” cycle, the load is de-energized, the timer returns to the “Off” cycle and the cycling is repeated as long as input voltage is applied. Removal of input voltage will reset the timer to its pre-power condition.
