Instant & Operate Delay Timer
The Model 363 Instant & Operate Delay Timer offers precise control for industrial applications requiring timed operations. Its digital adjustment provides a wide timing range, from 0.1 seconds up to 1023 minutes, accommodating diverse operational requirements. With a repeatability of ± 0.1% and an accuracy of ± 2%, consistent performance is maintained across its operational lifespan. The unit supports versatile voltage inputs, from 10-28V AC/DC to 40-260V AC/DC, enhancing its adaptability in various system configurations. Designed for robust environmental conditions, it functions reliably from -20°F to +140°F and tolerates 0-97% humidity without condensation. Featuring two SPDT relays and 775V transient protection, this timer is engineered for dependable, long-term service in demanding industrial settings. Its UL Recognized and CSA Certified status further assures compliance and operational integrity.
Instnt&Op Dly Tmr
Specifications
| Adjustment Type | digital |
|---|---|
| Voltage | L = 10-28V AC/DC; H = 40-260V AC/DC |
| Timing range | .1SEC: 0.1 - 102.3 Sec.; 1SEC: 1 - 1023 Sec.; 1MIN: 1 - 1023 Min. |
| Accuracy | ± 2% |
| Repeatability | ± 0.1% |
| Operating temp | -20°F to +140°F |
| Recycle time | 100ms |
| Contacts | Two SPDT Relays |
| Contact rating | 10A at 240VAC resistive |
| Transient protection | 775V, 80 Joules |
| Humidity tolerance | 0-97% w/o condensation |
| Enclosure material | NORYL Plastic |
| Mounting | 8-pin socket (not included) |
| Agency approval | UL Recognized and CSA Certified |
| Config: Voltage | L (10-28V AC/DC), H (40-260V AC/DC) |
| Config: Timing Range | .1SEC, 1SEC, 1MIN |
| Config: Additional Options | /C = Custom (Voltage and/or Timing), /SG = Silver with Gold Flash Contacts |
| Input Power | 3 Watts Max |
| Output (Resistive) | 240V AC, 10A |
| Output (General Use, 120V AC) | 4A |
| Output (General Use, 240V AC) | 2A |
| Output (Pilot Duty) | C300 |
| Pilot Duty (120V) | Make 15A, Break 1.5A |
| Pilot Duty (240V) | Make 7.5A, Break 0.75A |
| Warranty | 5-Year unconditional warranty |
| LED Indicator (Green) | Energized |
| LED Indicator (Red) | De-energized |
| LED Indicator (Flashing) | Relay is Timing |
